General
Brand
- Deepcool
Model
- R-PC350D-NA0B-BE
Microless SKU
- 107804
Date first available
- 25 July, 2022
Shipping Weight
- 0.25 Kg
Shipping Dimensions
- 15.00 cm x 15.00 cm x 6.30 cm
Form Factor
- ATX
Efficiency
- 80 Plus Bronze
Modular
- Semi-Modular
PFC
- Active
Fanless
- No
Color
- Black
Connectors
Main Connectors
- 1 x 24 pin ATX
EPS/CPU Connectors
- 2 x 8 pin (4+4) EPS (CPU)
SATA Power Connectors
- 8
Molex Connectors
- 3
PCIe 6-Pin Connectors
- 0
PCIe 6+2-Pin Connectors
- 4
PCIe 8-Pin Connectors
- 0
PCIe 12-Pin Connectors
- 0
PCIe 12+4-Pin 12VHPWR Connectors
- 0
—————————————— - Type ATX12V V2.5
- Product Dimensions 150×140×86mm
- 80PLUS Certifications BRONZE
- Fan Size 120mm
- Fan Bearing Sleeve Bearing
- Topology Active PFC+Dual Forward + DC to DC
- Capacitors Japanese Bulk Capacitor
- Power Good Signal 100-150ms
- Hold Up Time ≥16ms
- Efficiency ≥85% Under Typical Load
- Protection OPP/OVP/SCP/OTP/OCP
- Operation Temperature 0-40°C
- Erp Regulation ErP 2013
- MTBF 100,000 Hours
- Warranty 6 Years
