The Ultimate Platform for Gamers and Creators – Powered by GeForce RTX 40 Series and DLSS 3
New Streaming Multiprocessors
Up to 2x performance and power efficiency
Fourth-Gen Tensor Cores
Up to 4x performance with DLSS 3 vs. brute-force rendering
Third-Gen RT Cores
Up to 2x ray tracing performance
NVIDIA Ada Lovelace architecture
Realistic and Immersive Graphics
Dedicated Ray Tracing Cores
NVIDIA DLSS 3
NVIDIA Reflex low-latency platform
Built for Live Streaming
AI-Enhanced Voice and Video
NVIDIA Broadcast app
Fast-Track Your Creativity
Performance and Reliability
Game Ready and Studio Drivers
AXIAL-TECH UPGRADES – Air Superiority
Bigger and better. Axial-tech fans spin on dual-ball bearings and have been scaled up to propel 21% more air through the card, setting the stage for lower temperatures, less noise, and higher performance.
NEW DIRECTION – Well-maintained Formation
The two side fans spin counterclockwise to minimize turbulence and maximize air dispersion through the heatsink. All three fans come to a standstill when GPU temps are below 50 Celsius, letting you play less-demanding games or perform light tasks in relative silence. Fans start up again when temps are over 55 Celsius, referencing a speed curve that balances performance and acoustics for work or play.
3.25-SLOT DESIGN – Phase That Blaze
A vapor chamber and generously oversized heatsink combo efficiently soak up heat from the GeForce RTX 4070 Ti GPU so that it can be whisked away by the three Axial-tech fans.
MILITARY-GRADE 20K CAPACITORS – Resilient Squadron
A lineup of capacitors rated to last 20,000 hours at 105 Celsius brings higher temperature and ripple tolerance to the GPU power rail, arming the card for long-term deployment in challenging conditions.
COMPACT PCB – Power and Purge
Component and trace layouts have been optimized onto a short PCB to reduce power losses and let heat escape through a massive backplate vent.
METAL EXOSKELETON – Suit Up
A high-quality diecast shroud and aluminum backplate prevent PCB flex and feature large vents to further increase heat dissipation.
LOCK, LOAD, AND LET THE PERFORMANCE FLOW
The GeForce RTX 4070 Ti gloriously presented on a backdrop of low noise and rugged durability.
AUTO-EXTREME TECHNOLOGY – RELIABILITY BOOST
Auto-Extreme Technology is an automated manufacturing process that sets new standards in the industry by allowing all soldering to be completed in a single pass. This reduces thermal strain on components and avoids the use of harsh cleaning chemicals, resulting in less environmental impact, lower manufacturing power consumption, and a more reliable product overall.
AURA SYNC – Light ’em Up!
Aura-compatible ARGB lighting on the shroud adds a dash of customizable color or functional effects to your build. Pair up with a vast range of compatible system components and coordinate the glow to create a theme that’s uniquely you.
GRAPHICS CARD HOLDER – Pillar of Support
The bundled graphics card holder banishes sag and also contains a screwdriver to help you build.
GPU Tweak III
ASUS GPU Tweak III is more intuitive and feature-rich than ever before. A revamped interface offers greater accessibility by integrating core functions into a centralized dashboard, and our Voltage-Frequency tuner has been overhauled to make overclocking even easier. Additional goodies like 0dB fan technology, automatic profile swapping, a fully customizable on-screen display, and logging capabilities ensure that you get the most out of your graphics card.
QuantumCloud is a safe and easy-to-use application that lets you effortlessly earn extra money by sharing your graphics card’s computing power. Earnings are accessible through your PayPal or WeChat account, and QuantumCloud also supports multiple exchange methods, including Steam. In addition, QuantumCloud doesn’t collect any personal data, so your privacy stays protected. Get started right away with just one click!
Game Ready Drivers
GeForce Game Ready Drivers deliver the best experience for your favorite games. They’re finely tuned in collaboration with developers and extensively tested across thousands of hardware configurations for maximum performance and reliability.
Capture and share videos, screenshots, and live streams with friends. Keep your drivers up to date and optimize your game settings. GeForce Experience lets you do it all. It’s the essential companion to your GeForce graphics card.
Get smooth, tear-free gameplay at high refresh rates, plus HDR and more. This is the ultimate gaming display and the go-to equipment for enthusiast gamers.
Turn your screenshots into art with this powerful in-game photo mode that captures 360, HDR, and super-resolution photos.
The highest performance graphics deliver the smoothest, most immersive VR experiences.
Resizable BAR is an advanced PCI Express feature that enables the CPU to access the entire GPU frame buffer at once, improving performance in many games.
|Interface||PCI Express 4.0|
|GPU Series||NVIDIA GeForce RTX 40 Series|
|GPU||GeForce RTX 4070 Ti|
|Core Clock||2310 MHz|
|Boost Clock||2760 MHz|
|HDMI||2 x HDMI 2.1a|
|DisplayPort||3 x DisplayPort 1.4a|
|Max Resolution||7680 x 4320|
|Thermal Design Power||285W|
|Recommended PSU Wattage||750W|
|Power Connector||1 x 16-Pin|
|Max GPU Length||305 mm|
|Slot Width||3.25 Slot|
