Enjoy the read/write performance of PCIe Gen4x4
It supports the latest PCIe Gen4x4 with up to 3500/3200 MB/s[1], offering superior performance which is 7 times faster than typical SATA SSD, while also downward compatible with PCIe 3.0 specification.
Patented ultra-thin graphene heat spreader
The use of patented ultra-thin graphene heat spreader provides the best thermal conductivity material and assembly flexibility, allowing gamers to easily DIY on their own, and any motherboard heat spreader can be supported without interference.
Not only faster but also more stable and durable
Supporting SLC Cache technology and smart algorithm management mechanism can help ensure operational efficiency and maximize the performance of SSD. It is a reliable and trustworthy choice for data storage.
Supports the latest NVMe 1.4 standard
By supporting the latest NVMe 1.4 specification and optimizing the work division mechanism of NVM Sets and PLM (Predictable Latency Mode), it can effectively reduce latency time and the write loss and improve the QoS of the system. The use of the latest RRL (Read Recovery Level) technology can also improve the service life of SSD.
SSD smart monitoring software
TEAMGROUP provides an exclusive SSD smart monitoring software. It can keep track of the status of the products at any time, monitor their quality and performance, and then perform quick and easy related setup and testing.
Five-year warranty offers you peace of mind
The T-FORCE lab has conducted rigorous quality tests and provides a five-year warranty, so you can use it with peace of mind.
T-FORCE
T-FORCE is TEAM force. The red “T” on the logo of “TF” represents TEAMGROUP’s passion for the storage products. The black “F” represents TEAMGROUP’s over 18 years of promotion of storage products. The visual design of the perfect combination elegantly symbolizes a pair of flying wings. They represent that the high quality and extreme performance gaming products from TEAMGROUP are capable of allowing all gamers to break the speed limit and enjoy the ever-changing world of gaming.
Product Specifications
| Model | CARDEA Z44L | |||
| Interface | PCIe Gen4x4 with NVMe | |||
| Capacity | 250GB / 500GB / 1TB/ 2TB[2] | |||
| Voltage | DC +3.3V | |||
| Operation Temperature | 0˚C ~ 70˚C | |||
| Storage Temperature | -40˚C ~ 85˚C | |||
| DRAM Cache | NO | |||
| Terabyte Written (TBW) | 250GB – 150TBW 500GB – 300TBW 1TB – 600TBW 2TB – 1200TBW[3] | |||
| Performance | Crystal Disk Mark: 250GB Read/Write: up to 3300/1400 MB/s 500GB Read/Write: up to 3300/2400 MB/s 1TB Read/Write: up to 3500/3000 MB/s 2TB Read/Write: up to 3500/3200 MB/s[1] | IOPS: 250GB Read/Write: 132K/985K IOPS Max 500GB Read/Write: 142K/357K IOPS Max 1TB Read/Write: 263K/382K IOPS Max 2TB Read/Write: 380K/550K IOPS Max[1] | ||
| Weight | 7g (PCBA) | |||
| Dimensions | 80.0(L) x 22.0(W) x 3.7(H) mm | |||
| Humidity | RH 90% under 40°C (operational) | |||
| Vibration | 80Hz~2,000Hz/20G | |||
| Shock | 1,500G/0.5ms | |||
| MTBF | 3,000,000 hours | |||
| Operating System | System Requirements:
| |||
| Warranty | 5-year limited warranty[5] | |||
[1] Transmission speed will vary according to different hardware/software conditions, therefore the data can only use for basic reference.
[2] 1GB=1,000,000,000 Bytes. In OS system, it would be displayed as 1,000,000,000 Bytes/1024/1024/1024 = 0.93GB
[3] Definition and conditions of TBW (Terabytes Written)are based on JEDEC standard
[4] PCIe SSD works best under WIN8.1 and WIN10 operating system. Windows Operating Systems earlier than Windows 8.1 does not support NVMe Driver natively. Users will need to install NVMe Driver prior installing the SSD.
[5] The SSD is based on the TBW or Warranty period.NOTES：
- All the test data is provided by TEAMGROUP’s laboratory and the information of test data is only for reference.
- We reserve the right to modify product specifications without prior notice.
